8 Stations Vitamin Effervescent Lab Tablet Press Machine With 25mm Diameter

China 8 Stations Vitamin Effervescent Lab Tablet Press Machine With 25mm Diameter supplier
8 Stations Vitamin Effervescent Lab Tablet Press Machine With 25mm Diameter supplier 8 Stations Vitamin Effervescent Lab Tablet Press Machine With 25mm Diameter supplier

Large Image :  8 Stations Vitamin Effervescent Lab Tablet Press Machine With 25mm Diameter

Product Details:

Place of Origin: SHANGHAI, CHINA
Brand Name: STH, TIANHE
Certification: CE, ISO, GMP
Model Number: ZP198

Payment & Shipping Terms:

Minimum Order Quantity: 1 UNIT
Price: Negotiation
Packaging Details: Fumigation free export packing case
Delivery Time: 15 - 30 days
Contact Now
Detailed Product Description
Product Name: Laboratory Tablet Press Type: Talet Pill Press Machine
Usage: Moringa, Candy , Salt,effervescent Tablet Shape: Round Tablet And Irregular Tablet
Applicable Industries: Manufacturing Plant, Machinery Repair Shops After-sales Service: Field Installation, Commissioning And Training
After Warranty Service: Video Technical Support, Online Support, Spare Parts Application: Pharmaceutical Food
Machinery Test Report: Provided Warranty: 1 Year
High Light:

small tablet press

,

r&d tablet press

8 Stations Vitamin Effervescent Lab Tablet Press Machine With 25mm Diameter



8 Stations Vitamin Effervescent Lab Tablet Press Machine With 25mm Diameter Quick Details:

- 8 or 10 station for D-tooling, 14 or 17 station for B-tooling

- with main pressure and pre-pressure

- with touch screen and PLC controlling system

- working stable and easy operation

- force feeder system is optional

- tablet ejection system is optional

- with micro printer (optional)





Application

It is a type of small output laboratory tablet press machine mainly suitable for use in R&D laboratories.



Features:

1. single roller, fully enclosed in compliance with GMP requirement.

2. speed adjustable by frequency inverter.

3. PLC and touch screen, friendly and easy to operate.

4. Digital display main pressure, tablet ejection force, tablet thickness, filling depth, rotation speed and output.

5. with main pressure and pre-pressure

6. overload protection for motor with emergency stop device.

7. force feeder is optional.



Technical Parameters:

Model ZP8 ZP10 ZP14 ZP17 ZP21 ZP23
Number of Stations 8 10 14 17 21 23
Tooling Standard D D B B BB BBS
Max Main Pressure (KN) 60
Max Pre-pressure (KN) 10
Max Tablet Diameter (mm) round tablet 25 25 18 18 13 11
irregular tablet 25 25 19 19 16 13
Max Filling Depth (mm) 16
Max Tablet Thickness (mm) 6
Max Turret Speed (r/min) 30
Max Production Capacity (pcs/h) 14400 18000 25200 30600 37800 41400
Motor Power (kw) 1.1
Overall Size (mm) 700×580×1630
Machine Weight (kg) 650



8 Stations Vitamin Effervescent Lab Tablet Press Machine With 25mm Diameter 0

Keywords:

laboratory tablet press machine, laboratory rotary tablet press, mini rotary tablet press
