Product Details:
Payment & Shipping Terms:
|
| Product Name: | Sugarcoating Machine | Applicable Industries: | Pharmaceutical, Foodstuff, Healthcare |
|---|---|---|---|
| Usage: | Food And Pharmaceutical, Food, Chocolate /Sugar /Tablet, Sugar Coating Machine | Condition: | New |
| Material: | Stainless Steel | Warranty: | 1 Year |
| After-sales Service Provided: | Video Technical Support, Online Support, Commissioning And Training | ||
| High Light: | 32r/min pharma coating machine,1000mm pan coating tablet machine,32r/min pill coating machine |
||
Coated Tablet Polishing Machine Candy Chocolate Coating Machine Tablet Film Coating Machine
BY Series Sugarcoating Machine
Application
These machines sugarcoat the tablets and pills for pharmaceutical and food industries. It is also used for rolling and heating beans and edible nuts or seeds. This machine has advantages of simple structure, easy operation, and smooth surface. It can save accessories and it is also easy to maintain.
Main technical specifications
| Model | BY800 | BY1000 | BY1250 |
| Dia. of coating pan | 800mm | 1000mm | 1250mm |
| Production capacity | 30-50/kg | 50-70/Kg | 80-150/kg |
| Rotary speed of coating pan | 32r/min | 32r/min | 28r/min |
| Adjustable angle of inclination | 15 -45 | 15 -45 | 15 -45 |
| Motor power | 1.1kw | 1.5kw | 2.2kw |
| Power of blower fan | 200w | 200w | 370w |
| Outline dim.(mm)(L x W x H) | 1150x 800 x 1600 | 1150 x 1100 x 1430 | 1340 x 1250 x 1680 |
| Internal and external heating power | 1500w /2000w | 1500w /2000w | 2000w/ 2000w |
| Weight | 240kg | 250kg | 400kg |
Company information
Shanghai Tianhe Pharmaceutical Machinery Co.,ltd. (Brand STH) is founded by reorganizing the former Donghai Branch Factory of Shanghai No.1 Pharmaceutical Machinery Factory in 2000.The floor area of our factory covers 19,900 Square meters. Our registered trademark is "TH" and "STH".
STH was rewarded as a product-export type enterprise, which has the right of self import&export by ministry of Foreign Trade and Economic Cooperation of the People's Republic of China.
STH is specialized in the manufacture of pharmaceutical machinery and packaging equipment. All tasks from casting to metal machining and general assembly are accomplished by ourself. STH is a high-technology enterprise, which unites R&D new products and import&Export trade as one body.
We are not only the largest professional factory who is specialized in producing tablet press machines, but also the traditional manufacturer with a long history of over 30 years in producing pharmaceutical machinery and packaging equipment in China.
STH has obtained customers' trust and satisfaction depending on its fast development of new products, good quality, complete varieties, excellent service and economical price. Our products have serviced for over 3000 customers covered all the parts of China and been well exporting to over 60 countries and regions around the world. ” STH ” and ‘TH 'brand ZP series Rotary Tablet Presses continuously won the title of ‘The Brand Name Products of Shanghai 'from 2002 and won the awards of ‘National Major New Product', 'Shanghai Major New Product', 'Shanghai Patent New Product' and ‘Shanghai Commercialization Project of Research Findings' etc.
We have formed the production capacity of supplying the complete equipment from raw material pulverizing, vibrating, wet mixing, granulating, drying, group mixing to tablet coating, filling, packing, cartoning, sealing, boxing etc. The applicative coverage of our machines is extending to ceramic, chemical, powder metallurgical and electronic industry.
.
OUR CUSTOMERS
Our products have covered all the parts of China and been well exporting to over 30 countries and regions around the world. We have taken the leading position in the industry due to our ability to supply complete sets of equipment and large volumes of annual sale. The trademark of 'Tianhe' is enjoying a good reputation in domestic and overseas markets, winning the favorable comments of the customers at home and abroad.
OUR PRODUCTS
” STH ” and ‘TH 'brand ZP series Rotary Tablet Presses continuously won the title of ‘The Brand Name Products of Shanghai 'from 2002 and won the awards of ‘National Major New Product', 'Shanghai Major New Product', 'Shanghai Patent New Product' and ‘Shanghai Commercialization Project of Research Findings' etc.
OUR SERVICE
STH offers professional manufacturing and solution on Different Pharmaceutical Machinery and Packaging Materials.
1. Clients Inquiry and Consultation
2. Processing Solution Confirmation
3. Engineering and Manufacturing
4. Products Inspection
5. Shipment Arranging and Loading Job
6. Aftersales Service
PACKAGE
Whole machine and every parts wrapped by plastic film for dusting-proof.
Packed in export standard wooden case with pallet, conducive to forklift handling.
SHIPPING
Shipping method: by sea, by air, by international express company.
Delivery time: 30-45 days after order confirm.
Forwarder: We have shipping forwarder agent for sending the goods to all over the world, can arrange shippment to destination port and to door for customer. We also accept forwarder agent of customer.
FAQ
Q: Are you a factory or a trading company?
A: We are factory manufacturing pharmaceutical tablet press machines with more than 30 years' experience,and we provide perfect OEM and after-sale service.
Q: Can you send me the video to show how the machine works?
A: Certainly, we have made video of every machine and uploaded them to Youtube.
Q: How can I know your machine works well?
A: Before delivery, we shall test the machine working condition for you.
Q: How can I know your machine is designed for my product?
A: You can send us samples of your product and we test it on machine.
Q: Do you have a CE certificate?
A: For every model of machine, it has a CE certificate.
Your Satisfaction is Our Honor!
