Fully Automatic Lubrication High Speed Tablet Press Machine With Force Feeding System

Certification
Good quality High Speed Tablet Press for sales
Good quality High Speed Tablet Press for sales
STH products have excellent performance and work site environment are satisfied.

—— Miss Pattraporn Hiti,Davao, Philippines

They provide perfect service, products' working character meet.

—— Alina , California, USA

I'm Online Chat Now

Fully Automatic Lubrication High Speed Tablet Press Machine With Force Feeding System

China Fully Automatic Lubrication High Speed Tablet Press Machine With Force Feeding System supplier

Large Image :  Fully Automatic Lubrication High Speed Tablet Press Machine With Force Feeding System

Product Details:

Place of Origin: SHANGHAI, CHINA
Brand Name: STH, TIANHE
Certification: CE, ISO, GMP
Model Number: GZP620 series

Payment & Shipping Terms:

Minimum Order Quantity: 1 UNIT
Price: Negotiation
Packaging Details: Fumigation free export packing case
Delivery Time: 45 - 60 days
Contact Now
Detailed Product Description
Pressure: 100KN Main Pressure And 20KN Pre-pressure Material: Stainless Steel Coated And Safety Protection Windows
Feeder: Force Feeding System Output: Over 400,000 Tablets Per Hour
Lubrication: Fully Automatic Max Turret Speed (r/min): 70

High Quality High Speed Tablet Press Machine from China Biggest Tablet Press Manufacturer

Quick Details:
- high speed tablet press machine
- adopt TSM-type & EU-type international tooling
- suitable for large production capacity
- 100KN main pressure and 20KN pre-pressure
- suitable for hard forming raw material

Application
This machine is one kind of double side rotary tablet press machine, which can press granular materials into round shape tablet, irregular tablet or double-side engraved tablet.
This machine is mainly used in pharmaceutical, chemistry, foodstuff, electronic industries.

Feature:

  • High speed with large quantity punches, double press rollers, suitable for mass production.
  • Made of stainless steel, the housing is fully closed. The surface of the rotary turret is covered with a hardened layer so that the turret surface is wear resistant. The machine conforms to GMP requirements.
  • Perfect tableting system, twice compression forming, reasonable framework with proper space and big pressure roller, machine performance is reliable and no tablet weight difference.
  • Double impeller type force feeder, improve granules flow-ability and filling performance, ensure the filling precision.
  • Tooling track adopt double-side lifting structure, the punches are balanced stress and wear resistance.
  • High performance electrical control system, ensure each program processing precisely.
  • Automatic oil&grease central lubrication system, ensure the lubrication of pressure rollers, toolings and tracks, extending the working life of the machine.
  • Special oil proof, dust proof and noise proof design.


Technical Parameter:


Model GZPK-45GZPK-55 GZPK-65 GZPK-71
Number of Station45556571
Tooling StandardDBBBBBS
Max Main Pressure (KN)100
Max Pre-pressure (KN)20
Max Tablet Diameter (mm)Round Tablet25181313
 Irregular Tablet25191616
Max Filling Depth(mm)20181515
Max Tablet Thickness (mm)8766
Max Turret Speed (r/min)70
Max Production Capacity(pcs/h)378000462000462000462000
Motor Power (KW)11
Overall size (mm)1530*1250*1900
Machine Weight (kg)4300


Fully Automatic Lubrication High Speed Tablet Press Machine With Force Feeding System
