BG Series Automatic Tablet Film Coating Machine For Seeds Pharmacy

Certification
China Shanghai Tianhe Pharmaceutical Machinery Co., Ltd. certification
China Shanghai Tianhe Pharmaceutical Machinery Co., Ltd. certification
STH products have excellent performance and work site environment are satisfied.

—— Miss Pattraporn Hiti,Davao, Philippines

They provide perfect service, products' working character meet.

—— Alina , California, USA

I'm Online Chat Now

BG Series Automatic Tablet Film Coating Machine For Seeds Pharmacy

China BG Series Automatic Tablet  Film Coating Machine For Seeds Pharmacy supplier
BG Series Automatic Tablet  Film Coating Machine For Seeds Pharmacy supplier BG Series Automatic Tablet  Film Coating Machine For Seeds Pharmacy supplier

Large Image :  BG Series Automatic Tablet Film Coating Machine For Seeds Pharmacy

Product Details:

Place of Origin: SHANGHAI, CHINA
Brand Name: STH, TIANHE
Certification: CE, ISO, GMP
Model Number: GBS-10

Payment & Shipping Terms:

Minimum Order Quantity: 1 UNIT
Price: Negotiation
Packaging Details: Fumigation free export packing case
Delivery Time: 30 - 45 days
Contact Now
Detailed Product Description
Product Name: Pill Coating Machine ITEM/MODEL: GBS-10
Load Capacity: 10 Kg/batch Drum Rotation Speed(r/min): 3.0-19 RPM
Machine Power: 0.55 Kw Diameter Of Coating Drum: Φ500mm
High Light:

pill coating machine

,

tablet coater machine

BG Series Automatic Tablet Film Coating Machine For Seeds Pharmacy



BG Series Automatic Tablet Film Coating Machine For Seeds Pharmacy Quick Details:

- max 10kg per batch

- Explosion-proof

- adopts imported PLC man-machine interface

- automatic regulation negative pressure



BG Series Automatic Tablet Film Coating Machine For Seeds Pharmacy Application

The GBS series high-efficient sugarcoating and film coating equipment is mainly used in the pharmaceutical and foodstuff industries. This novel equipment, featured by high-efficient, energy-saving, safety, cleanliness and easy operation, is essential for Sugar, organic film, water soluble film-coating of tablets, pills and sweets.

PRINCIPLE:

The tablet cores to be film coated make continuous complicated orbital motion within the closed rotating drum under the action of a streamline guide plate. During the movement, coating medium is automatically sprayed according to the technological process and rational technological parameters assigned, coating, So that the coating medium sprayed on the surface of tablet cores, thus forming a solid and smooth surface film.



It can be used for coating various tablets, pills and sweets with organic film, water-soluble film and sugar film, etc. And it has such characteristics as high efficiency, low energy consumption and small floor area, etc. And it can be widely used for coating various tablets, pills and sweets with organic film, water-soluble film and sugar film etc. In such fields as of pharmaceutical, food and biological products etc.

And it has such characteristics as good appearance in design ,high efficiency, low energy consumption and small floor area, etc.
This machine is made of high-quality stainless steel elaborately and meets the tablets make complicated and constant track movement with easy and smooth turning and frequent exchanging in the clean and closed rotational cylinder of the film coating machine. And it can automatically spray coating medium according to the process flow and reasonable process parameters. The hot air exhausted through the bottom of the tablets under the effect of air exhaust and negative pressure so as to make coating medium dry quickly on the surfaces of the tablets and form a firm, fine and close and smooth surface film.



BG Series Automatic Tablet Film Coating Machine For Seeds Pharmacy Characteristics

  • The GBS series are made in compliance with the GMP standard in the pharmaceutical industry.
  • The case, coating dram, heat-air supplying cabinet and spray devices as well as every part in contact with medicine are wholly made of stainless steel.
  • The whole operation process is controlled either by a programming system of the microprocessor or manually, the control system has multi-functions of application programs, operation mode selection, drying control and multiple display.
  • Explosion-protecting devices are also equipped for the organic solvent for organic film coating.
  • With closed operation, neither dust flying nor spray splashing will appear.
  • Coating medium spraying, drying and exhausting can be carried out simultaneously for film coating, the whole processing van be completed only in 1-2 hours and for sugar coating, in 4-5 hours.
  • Equipped with an automatic material charge and discharge device.

Main technical specifications

ITEM/MODEL GBS-10
Load Capacity 10 Kg/batch
Drum rotation speed(r/min) 3.0-19 RPM
Machine Power 0.55 Kw
Diameter of coating drum Φ500mm
Power of air exhaust cabinet motor 0.75 Kw
Air exhaust flow 1285 m3/h
Power of hot air cabinet motor 0.37 Kw
Hot air flow 816 m3/h
Wight of man machine 200 Kg
Air consumption Pressure ≥0.4Mpa
Air consumption 0.2 m3/min



BG Series Automatic Tablet  Film Coating Machine For Seeds Pharmacy 0

BG Series Automatic Tablet  Film Coating Machine For Seeds Pharmacy 1



Our Company:

STH is a professional manufacturer and supplier of pharmaceutical and food chemicals machinery and equipment in China.We have a well-experienced team to manufacture pharmaceutical machinery and equipments and a professional design institute. With rich experiences in pharmaceutical machinery and equipment field and numbers of professional engineers, we have designed and developed many types of machinery and equipments including tablet press machine, soft-gel production line, granulator, mixer, dryers, pulverizer, packaging machine,soft and hard blister packing machine, capsule filling machines, cartoner etc.



We made the Standard, we beyond it. Welcome you come to STH for visiting and guiding.
