Product Details:
|
| Product Name: | GZPK-26 Series High Speed Rotary Tablet Press | Material: | Stainless Steel |
|---|---|---|---|
| Usage: | Pharmaceutical, Chemistry, Electronic Industries | Application: | Of GMP Standard |
| Feature: | Fully-closed, Observed- Clearly, Frequency Inverter-used | Weight(kg): | 1750 |
| Overall Size(mm): | 1380×1200×1900 | Motor Power (kw): | 7.5kw |
| Condition: | New | ||
| High Light: | Rotary Pharmaceutical Tablet Press,Foodstuff Pharmaceutical Tablet Press,80KN Pharmaceutical Tablet Press |
||
Single Side Series High Speed Fully Closed Rotary Tablet Press Machine
Application
This machine is one kind of single side rotary tablet press machine, which can press granular materials into round shape tablet, irregular tablet or double-side engraved tablet.
This machine is mainly used in pharmaceutical, chemistry, foodstuff, electronic industries.
|
Model |
GZPK-26 |
GZPK-32 |
GZPK-40 |
GZPK-44 |
|
|
Number of Stations |
26 |
32 |
40 |
44 |
|
Feature:
This machine is made of stainless steel,whose housing is fully closed. The surface of the rotary turret is covered with a hardened layer so that the turret surface is wear resistant. The machine conforms to GMP requirements.
The windows can be opened, cleaning and maintenance is easy
The upper and lower guide rails and punches are lubricated with an intermittent fixed low flow rate automatic lubricating system so as to reduce the wear of guide rails.
Hydraulic overload protection device is equipped.
A high precision pressure sensor is equipped with an amplifier provided with gaining and self-checking functions so as to implement self-checking of tablet compression pressure reliably.
Double impeller type force feeder, improve granules flow-ability and filling performance, ensure the filling precision.
Main Technical Specifications
|
Model |
GZPK-26 |
GZPK-32 |
GZPK-40 |
GZPK-44 |
|
|
Number of Stations |
26 |
32 |
40 |
44 |
|
|
Tooling Standard |
D |
B |
BB |
BBS |
|
|
Max Main Pressure (KN) |
80 |
||||
|
Max Pre-pressure (KN) |
20 |
||||
|
|
round tablet |
25 |
18 |
13 |
11 |
|
Max Tablet Diameter (mm) |
irregular tablet |
25 |
19 |
16 |
13 |
|
Max Filling Depth (mm) |
16 |
||||
|
Max Tablet Thickness (mm) |
6 |
||||
|
Max Turret Speed (r/min) |
90 |
100 |
110 |
110 |
|
|
Max Production Capacity (pcs/h) |
140000 |
192000 |
264000 |
291000 |
|
|
Motor Power (kw) |
7.5 |
||||
|
Overall Size (mm) |
1380×1200×1900 |
||||
|
Machine Weight (kg) |
1750 |
||||
FAQ:
Q: Where is your factory? How can I visit your factory?
A: Our factory is located In Chongming Shanghai. We warmly welcome you to visit our factory if you have a travel plan.
Q: How can I know your machine is designed for my product?
A: If you don't mind, you can send us samples and we will test on machines. During that time, we will take videos and clearer pictures for you. We can also show you on-line by video chatting.
Q: How about the after service and guarantee period?
A: We offer 12 months warranty since the arrival of the machine. Technical support is available 24/7. This is precautionary to ensure you have what you need if the machine has to be sent in for repair. We have professional team with experienced technician to serve abroad and do the best after service to assure the machine whole life usage.
Q: How long need to ship the machines after order?
A:We have ready stock for some model machine. and other machines can be ready and shipped in 15 to 30 days after order!
Q: What's the payment you prefer?
A: Our standard payment terms are T/T with 30% deposits and balanced before shipment.
Acceptable payment term.
Q:How to contact you?
A: Please leave messages and click "send" to send us inquiries.
Our Company
Shanghai Tianhe Pharmaceutical Machinery Co., Ltd. is the innovative leading manufacturer and professional total-solution supplier for pharmaceutical processing machines, packaging equipments and related service in Pharmaceutical & Food industry over 30 years.
We are a high-technology enterprise, all tasks from casting to metal machining and general assembly are accomplished by ourselves. We are dedicating ourselves to reinforce quality control and satisfactory clients based on detailed URS analysis and mutual communication.
Through continuous development, we have successively established good trade relations with about 2000 customers in China and our products are also well exporting to over 70 countries. Our annual sales are more than 10 million dollars.
Our mission is to provide our customer the most suitable qualified- product with best price and excellent service.
We are looking forward to building a long term and cooperative relationship with you. Please trust us as your most trustworthy friends!
